RASSOR ROBOT:- Rassor Robot scaled up and used for terrestrial mining operations like (in difficult-to-reach or dangerous locations for Mining).It also helps for autonomous sand mining. And extraterrestrial construction operations. RASSOR uses two bucket drum to complete its primary function of collecting and transporting solid Material. A bucket drum  is a novel device that mine, stores and dumps solid material. The rotary bucket design offers a solution to minimized friction. These buckets are mounted on the axes and return to their initial position. Rassor Generation Requirement RASSOR shall have a maximum mass of 50kg, with  a preferred mass of 20kg or less. RASSOR shall mine the top 5 cm of surface Solid material for nominal mining operations RASSOR shall be capable of mining 1 meter deep using a slot dozing trench method(A method of moving large quantities of material with a bulldozer. Each trip is made in the same path), for easy solid material mining and science observations RASSOR shall successfully mine 700 kg of solid material within 24 hours. The Solid material Trap shall designed for maximum interior capacity. Rassor shall able to  work on different surfaces for mining like sand, Rock Surface, etc. The Rassor shall have different types blades for material mining. Rassor Requirements solution After studying other designs, I came to the conclusion that the best way to give maximum interior capacity to the Rassor buckets is to use some sort of trap door. I believe I found a design that works extremely well, and isn’t too complex. Here I have used 2 types of blade for Mining Purpose. So that it is able to mine in different types of surface with effective manner. One blade is for only mine the hard material and break in to pieces and another one is for mine and collecting the materials. I have also used 3 types of wheel for moving on the Different surfaces. We can use it on plane , Rough and sand surface as our Requirements. For all this solution i have used Ekl as the Key Factor and change all the things in a second with one click.
